With the SR7013, the capability to bring it to unprecedented levels and with combining the latest in technology, Marantz has set the long standard for AV receivers bring in home theatre with an immersive experience with music and movies. The SR7013 includes 4K compatibility and 3D surround sound decoding formats that include Auro 3D with tuning and audio engineering.



For a home cinema experience, the Marantz SR7013 is designed to be the core of the home entertainment system, using nine amp channels that are built-in. With the unit supporting 11.2 channel processing, it means you can add external stereo amplifiers to the 11.2 setup if needed.



With the latest in HDMI and HDCP 2.2 specifications, the eight HDMI inputs and 3 outputs have made the SR7013 futureproof. Using 4K Ultra HD 60Hz, High Dynamic Range, Hybrid Log Gamma, 4:4:4 Pure Colour sub-sampling, 21:9 video, 3D, BT.2020 and Dolby Vision pass-through with every single input. In addition to the Enhanced Audio Return Channel, it brings full resolution 3D via ARC which is supported.



With the HEOS app, the wireless multi-room technology means that the SR7013 can integrate with the system. Explore and Browse your own music library or the online streaming service for thousands of music, along with internet radio stations using the HEOS app. With voice and wireless compatibility, you can use Bluetooth and Amazon Alexa/Echo devices to have a hands-free experience.



Features:

Marantz performance brings 11.2 channel AV Receiver.

4K/60Hz pass-through

4:4:4 Colour Resolution

High Dynamic Range

BT:2020

Dolby Vision

Hybrid Log Gamma

Full HDCP 2.2 Support with eight HDMI inputs and three HDMI outputs with 1 included at the front.

Enhanced Audio Return Channel Support, supporting formats like DTS:X and Dolby Atmos,

DTS Virtual:X, without the need for overhead speakers enjoy a immersive experience.

Quality of immersive sight and sound experiences

Hyper Dynamic Amplifier Module, with audio detail

Built-in WiFi

Built-in HEOS, for a whole house entertainment system

Use of Airplay, Bluetooth, Spotify, Internet Radio, Amazon Music and more, access to unlimited online music sources.

Music Formats using DSD, FLAC, ALAC and WAV support for audio streaming and gapless playback

Room Tone technology in which it optimizes for sound to be in the room.

Hands-free with the Amazon Alexa

Hassle-free installation

ECO Mode, a eco mode that doesn’t ruin the performance of the device



Benefits from IMAX Technology

The new technology programm from the IMAX, which brings a standard of images, sound, and content quality, feel like the IMAX is there with the immersive sound quality and clear pictures to match. Bring the support of object-based audio formats with the latest surround formats.



The Dolby Atmos and DTS:X

Bring the immersive audio sounds, which occur naturally in space and create lifelike experiences with the help of the Dolby Atmos and DTS:X with the sound engine from the DTS:X to bring a more natural use of a room’s sound. While the use of the Dolby Atmos, makes use of all your sound speaker systems to bring the greatest theatre experience.



Auro-3D

With life-like sound from the home theatre experience, to bring new levels of sound for music, broadcasting and films with your enhancing audio collection thanks to the the Auro-3D Mixing Engine.



High Grade

The Marantz SR7013 is built with the highest grade of components, with a Hyper Dynamic Amplifier which has being used on the Reference series, it provides low-noise with ultra-fast optimum sound quality with the latest in sound audio formats. Having a high-fidelity listening experience and a phono input, it can connect to your turntable to you to enjoy your vinyl collection.



Dual Subwoofer Outputs

The SR7013 supports two subwoofers: which can be used in two different locations, this can even out the sound and gives a more accurate sound quality and bass within the room at any place.



Smart TV Connectivity

With HDMI CEC, the SR7013 can connect with various Smart TVs with the use of the TV’s remote handset.



Specifications:

Multichannel Surround

DTS HD Master / DTS:X - yes/yes

DTS Neo:X / DTS Neural:X - no/yes

DTS Virtual:X - yes

Dolby TrueHD / Dolby Atmos - yes/yes

Dolby ProLogic Il / Dolby Surround - no/yes

Auro 3D - yes

Multichannel Stereo - yes

max. number of processing (preamp) channels - 11.2

IMAX Enhanced - yes

Sound Enhancements

Discrete Power Amplifier - 9

Power Transformer: Toroidal / EI - EI

Current Feedback Topology

Hyper Dynamic Amplifier Modules (HDAM)

Pure Direct

High Grade Audio Components

Gold plated RCA terminals

Clock Jitter Reducer

Audyssey - MultEQ XT32

Audyssey Dynamic EQ / Dynamic Volume

Audyssey LFC

Audyssey APP support

Compressed audio Enhancer: MDAX2

Network

HEOS Multiroom & Streaming

Lossy formats MP3 / WMA / AAC

Lossless formats FLAC / ALAC / WAV

Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24

DSD Audio Streaming - up to DSD5.6

FLAC HD 192/24

WAV 192/24

ALAC 192/24

Gapless playback - (FLAC, WAV, AIFF, ALAC, DSD)

AirPlay audio streaming

AirPlay 2 - (update)

Internet Radio - TuneIn

Spotify Connect* / Tidal* / Deezer* / others *

Compatible with Remote APP for Smart Phones - Android / iOS

Compatible with Remote APP for Tablets - Android / iOS/Amazon Kindle

Ethernet

WiFi

Bluetooth

AirPlay 2 audio streaming

HDMI

HDMI inputs back / front - 7 / 1

HDCP2.2 support

HDMI outputs main / zone - 2 / 1

Video conversion Analog -> HDMI

Analogue to HDMI scaling - 480i/576i up to 4K 60/50

HDMI to HDMI scaling - up to 4K 60/50

GUI Overlay on HDMI

HDMI: 3D / 4K / CEC / ARC

Enhanced ARC

Dolby Vision / HLG

4k signal pass-through / scaling / GUI overlay

HDMI pass-though in standby mode

Picture adjust / Noise reduction

CEC

DSD Audio capability

Audio Return Channel

Auto LipSync

Multiroom / CL

HEOS Multiroom integrated

TV Sound grouping

Multiroom zones - 3

Zone audio source: HDMI / opt, coax / Network, USB / analog - (2ch) / (2ch) / yes / yes

Zone audio output: speaker / preout

Zone HDMI output from HDMI source

Webbrowser User Interface

Smart Remote Management

IP control / RS232 control / Web control / App control

IR Flasher In

Marantz remote bus

DC Trigger output - 2

Others

Voice Control - Works with Amazon Alexa - (update)

Auto speaker setup by microphone - Audyssey MultEQ XT32

FL Display - 2 lines + port hole

Graphic User Interface - GUI - Advanced

ISF certification

GUI languages - 9

Setup Assistent

Smart Select

Firmware Update by Network / USB

Variable cross over

Optimized Bass Redirection

Bass Sync

ECO Mode

Auto Power off

Sleep Timer

Inputs/Outputs

Composite In / Out - 3+1 / 2

Component In / Out - 3 / 1

HDMI In / Out - 7+1 / 3

Multi-Room Video Out: Video / HDMI

Analogue In / Out - 5+1 / -

Phono (MM) In

Digital Inputs: Coaxial / Optical - 2 / 2

Multi-Room Out: analog - 2

Multichannel Pre Out - (11.2)

Subwoofer Out - 2 (independant)

7.1 multichannel input

Speaker Terminal: Gold plated screw

Number of speaker terminals - 11

Speaker A/B / Bi-amp drive / Multi-Room Speaker - assignable

Speaker A / B - assignable

Bi-amp drive - assignable

Multi-Room Speaker Terminal - assignable

Front Inputs: Audio / Composite / HDMI / USB

USB Audio / Made for iPod / Works with iPhone - yes / AirPlay / AirPlay

FM Tuner with RDS

Specifications

number of poweramps - 9

Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) - 125 W

Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) - 165 W

Power Output (6 ohm, 1 kHz, 1% 1ch Drive) - 200 W

70% Guarantee

General

Colour - Black

Metal Front Panel

System Remote Control - RC036SR

Power Consumption in W - 710

Power consumption No-Sound (ECO on / off) in W - 65 W / 110 W

Standby Consumption in W - 0.2

CEC Standby Consumption in W - 0.5



Maximum Dimensions

Antenna:Horizontal:(W x D x H) in mm - 440 x 411 x 185

( Antenna:Vertical :(W x D x H) in mm) - (440 x 411 x 247)

[w/o Antenna :(W x D x H) in mm] - [440 x 401 x 185]

Weight in kg - 14.2
