Yamaha RX-A6A AVENTAGE 9.2 Channel AV Receiver – Immersive Dolby Atmos & DTS:X Sound
Elevate your home entertainment with the Yamaha RX-A6A Aventage 9.2 Channel AV Receiver, a premium choice for immersive audio and cutting-edge technology. Engineered with SURROUND:AI™, HDMI™ 7-in/3-out, and the latest QCS407 processor, this Yamaha AV receiver delivers breathtaking clarity, dynamic sound, and future-ready connectivity.
9.2 Channels of Expansive Surround Sound
With 9.2 channels, the Yamaha A6A supports advanced configurations, bringing Dolby Atmos and DTS:X sound to life. Whether it’s a 5.2.4 setup with four ceiling speakers for deep immersion or 7.2.2 for wider sound distribution, your home cinema reaches new heights.
Upgrade to 11-Channel Cinematic Audio
Take your experience further by adding a stereo power amp for 11.2-channel surround sound, allowing four Atmos speakers or front-wide configurations for unparalleled depth.
SURROUND:AI™ – Intelligent Sound Optimization
With scene-by-scene audio processing, SURROUND:AI™ adjusts real-time sound dynamics, enhancing speech clarity, background audio, and effects. The result? A cinematic sound experience tailored to every moment.
Aventage Quality & Anti-Resonance Technology (A.R.T.)
Crafted for superior performance, the RX-A6A features A.R.T. construction, a H-shaped Cross Frame chassis, and a fifth damping foot to minimize vibration and maximize sound clarity.
High-Power Performance & Premium DACs
Packing 150W per channel, this AV receiver delivers dynamic and powerful sound. Paired with SABRE ES9026 PRO and ES9007S DACs, enjoy ultra-low distortion, crystal-clear detail, and high signal accuracy.
Next-Generation Connectivity
Designed for future-proof entertainment, this receiver supports 8K resolution, 4K/120Hz passthrough, and Dolby Vision, HDR10+ for vivid picture quality.
Optimized for Gamers
Game at the highest level with VRR, QFT, and ALLM, ensuring lag-free action and high-speed responsiveness.
MusicCast & Streaming Convenience
Enjoy Amazon Music, Spotify, Tidal, Deezer, Qobuz, and more with MusicCast multiroom capabilities. Apple AirPlay 2 and Bluetooth ensure wireless music streaming anywhere.
XLR Balanced Inputs for Professional Audio
Pro-level XLR balanced inputs provide enhanced noise resistance and long-cable compatibility, delivering studio-quality sound.
Transform your home entertainment with the Yamaha RX-A6A AV Receiver—the pinnacle of high-performance audio and cutting-edge technology.
What's in the box
- Yamaha RX-A6A Aventage 9.2 Channel AV Receiver, Black
- DAB/FM antenna
- Power cable
- YPAO microphone
- YPAO microphone base and pole
- Remote control
- Two AAA batteries (for remote control)
- Quick start guide
- Safety brochure
Technical Specifications
Dimensions
| Dimensions (W x H x D) |
435 x 192 x 442 mm |
| Dimensions with antenna up (W x H x D) |
435 x 271 x 442 mm |
| Weight |
20.3 kg (Varies by region) |
Amplification
| Channel rated output power (1kHz, 1ch driven) |
9.2 |
| Rated Output Power (1kHz, 1ch driven) |
185 W (8 ohms, 0.9% THD) |
| Rated Output Power (20Hz-20kHz, 2ch driven) |
150 W (8 ohms, 0.06% THD) |
| Maximum Effective Output Power (1kHz, 1ch driven) |
220 W (8 ohms, 10% THD) |
| High slew rate amplifier |
Yes |
| Standby power consumption (IR only) |
<0.4 W |
| Auto power standby |
Yes |
| ECO mode |
Yes |
Surround Sound Processing
| Surround: AI |
Yes |
| CINEMA DSP |
Yes (HD3) |
| DSP programs |
24 |
| Dialogue level adjustment |
Yes |
| Virtual presence speaker |
Yes |
| Virtual surround back speaker |
Yes |
| Dialogue lift |
Yes |
| Silent cinema / virtual cinema DSP |
Yes |
| Dolby Atmos |
Yes |
| Dolby Atmos Height Virtualiser |
Yes |
| Dolby TrueHD |
Yes |
| Dolby Digital Plus |
Yes |
| Dolby Surround |
Yes |
| DTS:X, DTS-HD Master Audio |
Yes |
| Auro 3D® |
Yes (via firmware update) |
Audio Features
| File format |
MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz |
| Pure direct |
Yes |
| Compressed music enhancer |
Yes |
| High-resolution music enhancer |
Yes |
| YPAO™ multi-point measurement |
Yes with R.S.C. (reflected sound control), 3D, 64-bit High Precision EQ calculation and angle measurement |
| YPAO™ volume |
Yes |
| Adaptive DRC (Dynamic range control) |
Yes |
| Initial volume & maximum volume setting |
Yes |
| A.R.T. wedge |
Yes |
| Bi-amp capability |
Yes |
| Audio delay |
Yes (0-500 ms) |
| DA converter |
384 kHz / 32-bit ESS hyperstream DAC ES9026PRO x1 ES9007S x1 |
Video Features
| HDMI eARC |
Yes |
| HDMI audio return channel |
Yes |
| HDMI pass-through |
8K60AB, 4K120AB (via future update) |
| HDMI up-scaling |
Yes, up to 8K (via firmware update) |
| HDMI up-conversion |
Yes (Analog to HDMI) |
| Dolby Vision |
Yes |
| HDR 10+ |
Yes (via firmware update) |
| VRR/ALLM/QMS/QFT |
Yes (via firmware update) |
| Video adjustment |
Yes |
Connectivity
| MusicCast surround |
Yes |
| HDMI input/output |
7 / 3 (HDMI 2.1 / HDCP2.3) |
| HDMI CEC |
Yes |
| USB input |
Yes |
| Network port |
Yes |
| Wi-Fi |
Yes (2.4 / 5 GHz) |
| AirPlay 2 |
Yes |
| Bluetooth |
Yes (SBC / AAC) |
| Front AV input |
USB |
| Digital audio input/output: Optical |
3 / 0 |
| Digital audio input/output: Coaxial |
2 / 0 |
| Analog audio input/output |
6 / 0 |
| Phono input |
Yes |
| XLR terminal |
Yes |
| Component video input/output |
1 / 0 |
| Composite video input/output |
2 / 0 |
| Pre-out |
11.2-ch |
| Headphone output |
1 |
Tuner
| FM/AM tuner |
Yes (availability varies by region) |
| DAB tuner |
Yes (availability varies by region) |
User Interface
| On-screen display |
Graphical user interface |
| Scene |
Scene plus (8 sets) |
| App control |
Yes (iPhone / iPad / android phone / tablet) |
| Web browser control |
Yes |
| Remote control unit |
Yes |
Zone Control
| Zone 2 audio output |
Pre-out / HDMI |
| Zone 3 audio output |
Pre-out |
| Zone 4 audio output |
HDMI |
| Powered zone |
Zone 2 / 3 |
| Zone video output |
HDMI |
| Zone B output |
HDMI |
| Zone GUI |
Yes |
| +12V trigger output |
2 |
| Remote (IR) input/output |
1 / 1 |
| Party mode |
Yes |
