Wharfedale Diamond 12.3D Atmos Speakers Pair Black Oak
In the world of high-fidelity sound, Wharfedale’s iconic DIAMOND speakers have long been celebrated as the quintessential entry point. Garnering countless 'product of the year' awards worldwide, they offer an unmatched sonic value, truly redefining affordable, high-performance loudspeakers.
Embrace the Future of Surround Sound with the DIAMOND 12 3D Atmos Speaker
Embodying Wharfedale's legacy in home theater excellence, the all-new DIAMOND 12 3D surround speakers promise an immersive cinematic audio experience within the comfort of your own space. Unleash a dome of encompassing sound that brings movies to life and music to your soul, redefining your audio encounter.
Unparalleled Clarity with Klarity Technology
Harnessing the power of Klarity™ polypropylene cones, the DIAMOND 12 3D ensures unparalleled clarity and focus. Crafted with a unique blend of mica and polypropylene, these cones offer exceptional stiffness, reduced distortion, and lightning-fast response, guaranteeing an audio experience that's both accurate and enthralling.
Immersive Sound with Advanced Magnet System
Powered by an advanced magnet system and an aluminum compensation ring, the Klarity™ diaphragms deliver a distortion-free and rich audio encounter, minimizing variations in inductance as the voice coil moves. Enjoy an uninterrupted and immersive sound experience, free from any intermodulation disturbances.
Superior Voice Coil for Unmatched Performance
Built with a high-power epoxy/glass fiber bobbin, the voice coil of the DIAMOND 12 3D surpasses expectations, offering exceptional power handling and stiffness, all while minimizing eddy currents. Experience a truly unmatched performance that transcends its class, redefining the limits of audio excellence.
Crisp Highs and Wide Dispersion
The speaker features a 25mm dome made from a woven polyester film, coated to deliver extended, open, and crisp high frequencies. Optimized for wide dispersion and uncompressed behavior, the magnet system and front plate ensure an immersive, all-encompassing sound encounter that transcends limitations.
Optimal Resonance Reduction with Intelligent Spot Bracing
Equipped with Intelligent Spot Bracing, the speaker's cabinet achieves optimal reduction of resonance. Carefully designed to minimize the transfer of resonance between walls, this technology ensures a pristine and undisturbed audio encounter, allowing you to immerse yourself fully in the purity of sound.
Embrace the Wharfedale Diamond 12.3D Atmos Speakers Pair to unlock a new dimension of audio indulgence. Transport yourself into a world of immersive sound, where every note and every word comes alive with unparalleled precision and depth.
Technical Specifications
General Description |
2-way vertical channel speaker |
Enclosure Type |
closed-box system |
Transducer Complement |
2-way |
Bass Driver |
4"(100mm) advanced PP Cone |
Treble Driver |
1"(25mm) Textile Dome |
AV Shield |
No |
Sensitivity (2.83V @ 1m) |
85dB |
Recommended Amplifier Power |
20-100W |
Peak SPL |
95dB |
Nominal Impedance |
8Ω Compatible |
Minimum Impedance |
4.3Ω |
Frequency Response (+/-3dB) |
110Hz ~ 20kHz |
Bass Extension (-6dB) |
90Hz |
Crossover Frequency |
3kHz |
Cabinet Volume (in litres) |
2.7L |
Height (with grille) |
145mm |
Width |
180mm |
Depth (with terminals) |
310mm |
Carton Size |
380 x 315 x 255mm |
Net Weight |
3.2kg/pcs |
Gross Weight |
7.2kg/ctn |
Finish |
Black Oak/Walnut Pearl/Light Oak Vinyl |
Standard Accessories |
Rubber feet |
Optional Accessories |
Wall bracket |
