Monitor Audio W2M Creator Series In-Wall Speaker Single
Introducing the Tier 2 in-wall loudspeaker – a medium-sized masterpiece designed for those seeking pristine and engaging acoustics with high-performance sound. This three-way model boasts two RST II bass drivers, an RST II mid-range driver, and a C-CAM tweeter, delivering clear and lifelike high-fidelity sound that aligns with the exceptional quality expected from any Monitor Audio passive box loudspeaker. With a convenient cut-out dimension of 527 x 198 mm, installation is made effortless through the revolutionary patented Quik-Link speaker cable connector and the evolved Tri-Grip II, ensuring a quick, reliable, and robust fitting process. Elevate your audio experience with the Tier 2 in-wall loudspeaker, where cutting-edge technology meets superior sound quality for an immersive integration into any space. Upgrade your sound with Monitor Audio's dedication to excellence in audio engineering!
Key Features
- Ideal for installations where pristine acoustic performance is required
- Three-way design
- 1 x 1" (25 mm) C-CAM tweeter with UD Waveguide II for lifelike sound
- 1 x 3" (76 mm) RST II mid-range driver
- 2 x 5" (127 mm) RST II bass drivers for full bass
- Patented Quik-Link speaker cable connector for quicker installation
- Tri-Grip II for easy and secure fitment
General Information
-
Enclosure Type: Open
-
Output: Mono
-
Power Type: Passive
-
Weight Each (Kg): 3.9
Application Appearance
-
Visible Colour: White
-
Visible Shape: Rectangular
Dimensions
-
Cutout Dimensions (mm): 527 x 198
-
Mounting Depth (mm): 85
-
Overall Depth (mm): 90
-
Overall Dimensions (mm): 540 x 211
Detailed Specifications
-
Compatible Amplifier (Watts RMS): 45 - 180
-
Frequency range (Hz): 40 - 35000
-
Nominal Impedance (Ω): 6
-
Max Power High (Watts): 120
-
Sensitivity (dB): 87
-
Sound Pressure (dB): 116
Driver Information
- Bass: 2
- Biggest Driver Size (mm): 127
- Mid: 1
- Tweeter: 1
