LG G1DGBRLLK 3.1ch Wireless Dolby Atmos Soundbar and Subwoofer
Features
A perfect match with LG 55” G1 OLED TV
Cinematic three dimensional sound with Dolby Atmos
Fantastic depth of sound (360W, 4 channels)
AI Sound Pro for optimised audio
Optimal connectivity
4K Pass Through
Artfully Completed
The G1 sound bar has been designed to perfectly and seamlessly match your LG 55” G1 OLED TV – wall-mounted directly below the TV with a flush fitting and slim profile.
A Premium Addition to Your Home
The LG Sound Bar G1 was also designed with your home in mind. It's slim profile and premium materials are the perfect fit for any interior.
Hear the Difference with Immersive 3D Sound
The LG Sound Bar G1 meets Dolby Vision, Dolby Atmos and DTS:X to transform your home into a cinema, for the most immersive viewing of all your favourite movies.
Fil the Room with the Ultimate Cinematic Surround Sound
The LG Sound Bar G1 supports wireless connectivity for 3.1 ch output so you can always watch TV with the most immersive sound.
Listen to Uncomparable Sound
High Resolution Audio delivers 96kHz sampling rates and 24bit depth, for more accurate sound and a more enjoyable listening experience.
Adaptive Audio for Everything You Watch
AI Sound Pro automatically analyses content to instantly optimise audio settings for what's playing. Catch every detail with crystal clear dialogue or more punchy powerful action, depending on the genre.
Audio & Visuals Seamlessly In-sync
The LG Sound Bar G1 delivers 4K content, including HDR and Dolby Vision, with no loss to quality or performance for a fully connected TV & audio experience.
Connect More Conveniently
Add Bluetooth® connectivity to your audio setup, or conveniently connect and play using optical, USB or HDMI cables.
Change to Suit Your Situation
LG Soundbar G1 can stand or be wall-mounted depending on your interior, so you can complete your setup the way you want.
Specifications
MODEL INFORMATION
Brand Information LG Sound Bar
Model Name G1
Subwoofer Model Name SPN5-W
System (Main Chip) MT8531
Mainset / Subwoofer Colour Black/Dark Silver (Top)
SIZE(W X H X D, MM)
Main (w/ Foot ) 1225 x 150 x 32.5
Matching TV size (`20 New) 55 inch ↑
Subwoofer 180 x 394 x 290
MATERIAL
Main - Front / Top / Bottom Jersey/Mold/Aluminum
Subwoofer - Front / Body Jersey/Wood
WEIGHT(KG)
Main TBD
Subwoofer 5.8Kg
Gross Weight TBD
CARTON BOX
Size (W x H x D) mm 1296 x 436 x 251
Type Flexo
Colour Yellow
CONTAINER Q'TY
20ft 19040ft 405
40ft (HC) 477
NUMBER OF CHANNELS
Number of channels 3.1ch
OUTPUT POWER(THD 10%)
Total 360W
Front 50W x 2
Center 40W
Subwoofer 220W(Wireless)
SPEAKER UNIT FRONT(L/R)
SPL 83dB
System Closed Box
Tweeter Unit 20mm (2EA)
Woofer Unit 3 Inch (2EA)
Impedance 4Ohm
SPEAKER UNIT CENTER
SPL 83dB
System Closed Box
Woofer Unit 2.3 Inch
Impedance 4ohm
SPEAKER UNIT SUBWOOFER
SPL 85dB
System Bass Reflex
Woofer Unit 6 inch
Impedance 3ohm
NO. OF SPEAKER UNIT
Number of speakers 6EA
CONNECTIVITY GENERAL
Optical Yes (1)
HDMI 2.1 (HDCP 2.3) - In / Out Yes (1)/Yes (1)
HDR10 / HDR10+ Yes/-Dolby Vision Yes
USB Yes
CONNECTIVITY WIRELESS
Bluetooth Version 4.0
Bluetooth Codec - SBC / AAC Yes/Yes
Wireless Rear ready Yes (1:1)
DISPLAY INFORMATION
Display Type LCD (5 char.)
HI-RESOLUTION AUDIO
Sampling - "24bit/192kHz" / "24bit/96kHz" X/YesUpbit/upsampling - "24bit/192kHz" / "24bit/96kHz" X/Yes
SOUND EFFECT
AI Sound Pro Yes
Standard Yes
Music Yes
Cinema Yes
Bass Blast / Bass Blast + Yes
Dolby Atmos Yes
DTS:X Yes
SOUND CONTROL
User EQ - RCU / App X/Yes
Night Time On/Off - RCU / App X/Yes
Dynamic Rage On/Off - RCU / App X/Yes
Auto Volume Leveler On/Off - RCU / App X/Yes
Surround On/Off - RCU / App X/Yes
CONVENIENCE
Remote App - iOS / Android OS X/Yes
Smart Phone File Playback (Bluetooth) Yes
NSU / FOTA X/Yes
Control with your TV Remote (Vol+/-, Mute) Yes/Yes
Sound Sync - Bluetooth(LG TV) / Optical Yes/Yes
Auto Power On/Off - Bluetooth (LGTV) / Optical Yes/Yes
Auto Power On/Off - RCU / APP Yes/Yes
A/V Sunc (0~300ms) - RCU / APP X/Yes
HDMI SIMPLINK Yes
HDMI Audio Return Channel (ARC) Yes
Woofer Level (-15 ~ 6dB, 1dB/Step) Yes
HDMI Audio Return Channel (e-ARC) Yes
Channel Level (-6 ~ 6dB, 1dB/Step)
- Top / Center / Surround / Rear / Rear Top X/Yes/X/Yes/X
Mute Yes
Auto Dimmer YesUSB Host / Charge Yes/X
Built-in Music Yes (1 song)
Bluetooth Stand-By Yes
AUDIO FORMAT(BITSTREAM)
LPCM Yes
Dolby Atmos Yes
Dolby TrueHD Yes
Dolby Digital Plus Yes
Dolby Digital Yes
DTS:X Yes
DTS-HD Master Audio Yes
DTS-HD High Resolution Yes
DTS Digital Surround Yes
AAC / AAC+ Yes
FILE FORMAT
FLAC - C4A / USB X/Yes
OGG - C4A / USB X/Yes
WAV - C4A / USB X/Yes
MP3 - C4A / USB X/Yes
WMA - C4A / USB X/Yes
AAC - C4A / USB X/Yes
POWER MAIN
Adapter 25V, 2A
Power Off Consumption 0.5W ↓
Power Consumption TBD
POWER SUBWOOFER
Type (SMPS) 100~240V, 50/60Hz
Power Off Consumption 0.5W ↓
Power Consumption 33WWireless Frequency 5GHz
ACCESSORY MANUAL
Web Manual (File) Yes (Full)
Built-in Manual (Book) (Simple or Full) Yes (Simple)
Wall Mount Guide Yes
Open Source - Yes (Full or Simple) / X Yes (Full)
Warranty Card Yes
ACCESSORY REMOTE CONTROL
Model Name MA6
Battery(Size) AAA x 2
Battery Built-in Yes
ACCESSORY OTHERS
Wall Mount Bracket / Stand Bracket Yes/Yes
HDMI Cable Yes
